LMS1-GA Automatic Transfer Switch(ATS) 16-3200A Motor
LMS1-GA Automatic Transfer Switch(ATS) 16-3200A Motor
model:LMS1-GA
Rated current:16~3200A
Frame size:100、160、250、630、1600、3200
Rated voltage: AC400V 50Hz
Rated control voltage: AC230V
Rated impulse withstand voltage:8kV
Transfer time:<2.5s
model:LMS1-GA
Rated current:16~3200A
Frame size:100、160、250、630、1600、3200
Rated voltage: AC400V 50Hz
Rated control voltage: AC230V
Rated impulse withstand voltage:8kV
Transfer time:<2.5s
1. Product Overview
2. Key Specifications

| Parameter | Details |
|---|---|
| Model | LMS1-GA |
| Switching class | PC-class ( motorized) |
| Poles | 3P / 4P |
| Rated Current (In) | 16-3200A |
| Frame sizes | 100 / 160 / 250 / 630 / 1600 / 3200 A |
| Rated Operational Voltage (Ue) | AC 400V / 50Hz |
| Rated impulse withstand voltage | 8kV |
| Control Modes | Automatic, Manual (with key lock for manual mode) |
| Operating Category | AC-33B |
| Mounting Type | Panel mount (compact form factor) |
| Enclosure Rating | IP20 (front face) |
| Compliance Standards | IEC 60947-6-1, GB/T 14048.11, IEC 60947-6-1, GB/T 14048.11; CCC, CE |
| Operating Temperature | -10°C ~ +60°C |
| Mechanical Life | ≥10,000 operations |
| Transfer time | < 2.5 s |
3. Core Features
✅ PC-Class High-Reliability Design: Motorized, mechanically interlocked switching mechanism ensures safe, simultaneous-source prevention and zero-cross switching for critical loads.
✅ Key-Lock Safety Function: Manual mode is secured with a key lock, preventing unauthorized operation and ensuring safety during maintenance procedures.
✅ Compact Form Factor: Space-saving design suitable for installation in standard distribution panels and ATS cabinets, ideal for limited-space applications.
✅ Auto/Manual Operation: Selectable automatic transfer (based on power status) and manual control (key-locked) for maintenance or testing.
✅ Fail-Safe Interlock: Mechanical interlock eliminates the risk of cross-connection between the two power sources, ensuring compliance with electrical safety codes.
✅ High Withstand Capacity: 8kA short-circuit making and 5kA short-circuit connection capacity ensure stable performance under fault conditions.
✅ Robust Construction: Heavy-duty housing and high-quality contacts ensure reliable performance in demanding commercial and industrial environments.
✅ Clear Phase Markings: Color-coded phase terminals (A/B/C/N) simplify wiring and installation, reducing the risk of errors.
4. Applications
- Small to medium commercial building backup power systems
- Industrial facility critical load protection
- Telecommunications tower and base station power systems
- Retail and office building emergency power
- Generator rental and portable power units
- Remote site and off-grid power systems
5.Quality & Factory Support

6. Technical Documents & Support
- Download the full datasheet for detailed specifications, wiring diagrams, and installation instructions.
- Contact our engineering team for custom current ratings or OEM solutions for large-scale ATS projects.
- Request a quote with your project details for bulk pricing, lead times, and compliance certifications.
7. Related Products & Reading
- Automatic Transfer Switch category — the full ATS range
- LMS2 ATS (PC-class, 63–800A) — the compact PC-class ATS for smaller panels
- LMQ3-W1 MCCB ATS (CB-class, 125–630A) — integrated breaker protection in one unit
- LMW1 Air Circuit Breaker — upstream protection for the same distribution bus
- Thailand Automatic Transfer Switch Cabinet — how ATS fits a Thailand project
