UK5-HESI DIN rail fuse terminal block is a standard 35mm rail mounted fused connector rated 690V 0.5-20A equipped with built-in glass fuse holder for circuit overcurrent protection. Adopts full pure copper conductive fittings with anti-slip screw structure and anti-break foot design, V0 flame retardant insulating housing. Easy snap-on installation on DIN rail, widely used in low-voltage distribution boxes, industrial control cabinets and automation equipment. Factory direct supply with sufficient stock, bulk order discount and OEM customization service for global electrical export.
UK5-HESI DIN rail fuse terminal block is a standard 35mm rail mounted fused connector rated 690V 0.5-20A equipped with built-in glass fuse holder for circuit overcurrent protection. Adopts full pure copper conductive fittings with anti-slip screw structure and anti-break foot design, V0 flame retardant insulating housing. Easy snap-on installation on DIN rail, widely used in low-voltage distribution boxes, industrial control cabinets and automation equipment. Factory direct supply with sufficient stock, bulk order discount and OEM customization service for global electrical export.
1. Product Overview
2. Core Competitive Features
✅ Standard 35mm DIN Rail Snap-On Installation
Direct buckle mounting on universal 35mm DIN rail, no extra fixing tools needed, convenient dense arrangement together with circuit breakers and other modular electrical components.
✅ Built-In Replaceable Glass Fuse Holder
Integrated transparent glass fuse cavity, easy fuse replacement without dismounting the whole terminal block, real-time visible fuse status for quick circuit fault inspection.
✅ Thickened Full Pure Copper Conductive Fittings
All conductive contact parts adopt high-purity thick brass, excellent electrical conductivity, low contact resistance, no overheating under long-time stable load operation.
✅ Anti-Slip Screw Clamping Structure
Special thread screw design effectively prevents wire slipping after long-term vibration, ensures firm wiring connection and avoids loose contact heat risk.
✅ Reinforced Anti-Break Foot Structure
Strengthened plastic base foot, anti-fracture during repeated wire disassembly and assembly, durable for long-term frequent maintenance work.
✅ V0 Grade Flame Retardant Insulation Housing
Shell made of high temperature resistant V0 flame retardant PA plastic, anti-aging, insulation safe, effectively avoid fire hazard caused by abnormal circuit temperature.
✅ Stable Electrical Rating: 690V / 20A
Standard rated parameter matches most low voltage control circuits, applicable for signal circuit, control loop and small power auxiliary circuit protection.
✅ Factory Spot Stock & Bulk Discount Support
Source factory direct sales with abundant ready stock for fast shipment; more favorable unit price for large wholesale export orders, accept OEM private logo customization.
3. Main Product Specifications
| Item | Technical Parameter |
|---|---|
| Model | UK5-HESI Fuse Terminal Block |
| Mounting Standard | 35mm Standard DIN Rail |
| Rated Voltage | 690V |
| Rated Current | 0.5-20A |
| Built-In Accessory | Glass Tube Fuse Holder (Replaceable Fuse) |
| Housing Material | V0 Flame Retardant PA Insulation Plastic |
| Conductive Part Material | Thickened Pure Copper Brass |
| Wiring Advantage | Anti-slip screw clamp, reinforced anti-break foot base |
| Core Function | Circuit wiring + Overcurrent short-circuit fuse protection |
| Application | Low voltage distribution cabinet, industrial control panel, PV equipment |
| Service Support | Spot stock fast delivery, bulk discount, OEM customization for export |
4. Wide Application Scenarios
- Low voltage power distribution boxes & complete switchgear
- Industrial automation PLC control cabinets
- Solar photovoltaic combiner box auxiliary circuit protection
- Mechanical equipment machinery control panels
- Building intelligent electrical monitoring system
- Factory workshop small power signal control loop
- Elevator, air conditioner and electrical equipment control cabinets
5. Installation & Operation Guide
- Snap the UK5-HESI fuse terminal block firmly onto standard 35mm DIN rail, lock the bottom buckle to fix the terminal stably.
- Loosen the wiring screw, insert stripped copper wire into the wiring cavity, tighten the anti-slip screw to clamp wire tightly without slipping.
- Open the red top fuse cover, put matched 20A glass fuse into the internal holder, close the cover to complete fuse installation.
- Connect power supply and load circuit respectively on two sides of the terminal block, the fuse will blow automatically to cut off circuit when overload or short circuit happens.
- After fault troubleshooting, open the top cover and replace the blown fuse to restore normal circuit operation.
6. Frequently Asked Questions (FAQ)
Q1: What is the main function of UK5-HESI fuse terminal block?
Q2: Does this UK5-HESI terminal use pure copper conductive parts?
Q3: What is the rated voltage and current of UK5-HESI fused terminal?
Q4: Can the fuse inside UK5-HESI terminal be replaced separately?
Q5: Do you have spot stock for bulk export orders of UK5-HESI terminals?
7. Factory Wholesale Advantages
- Direct manufacturer production without middlemen, competitive ex-factory price for mass export orders.
- Strict raw material inspection and finished product aging test to ensure long-term stable performance.
- Professional electrical technical team provides terminal selection and wiring guidance for cabinet engineering projects.
- Sufficient production capacity to support large batch orders, fast delivery cycle with shockproof export carton packaging for sea transportation.
- Flexible OEM customization service including private logo printing, customized packaging and special specification adjustment for overseas market demands.
