CJX2-F AC contactor is a common electrical component for controlling loads such as AC motor. It is composed of arc extinguishing, contact, magnetic system, etc. . Through the coil on-off generation/disappearance of electromagnetic force, to achieve contact opening and closing to control the circuit. Adapt to AC 50/60Hz, to 1000V circuit, rated current 115A-800A, ambient temperature-25 °C to + 40 °C can work, widely used in industrial automation and motor drive field.
Model: CJX2-F/LC1-F
Rated current: AC -3 (115A-800A), AC-1 （200-1600A）
Rated control voltage: 24V-415V(the default is 220V)
Rated operational voltage: 1000V
Certification: CE
CJX2-F AC contactor is a common electrical component for controlling loads such as AC motor. It is composed of arc extinguishing, contact, magnetic system, etc. . Through the coil on-off generation/disappearance of electromagnetic force, to achieve contact opening and closing to control the circuit. Adapt to AC 50/60Hz, to 1000V circuit, rated current 115A-800A, ambient temperature-25 °C to + 40 °C can work, widely used in industrial automation and motor drive field.
Model: CJX2-F/LC1-F
Rated current: AC -3 (115A-800A), AC-1 （200-1600A）
Rated control voltage: 24V-415V(the default is 220V)
Rated operational voltage: 1000V
Certification: CE
1. Product Overview
2. Complete Technical Parameter Table
| Parameter Item | Standard Specification |
|---|---|
| Product Model Range | CJX2-F115, F150, F185, F225, F265, F330, F400, F500, F630, F800 (115A~800A) |
| Pole Number | 3 Main Poles (3P) |
| Rated Operational Current (AC-3, 380V) | 115A ~ 800A Optional |
| Rated Insulation Voltage | 1000V AC |
| Rated Working Voltage | 220V / 380V / 660V AC |
| Frequency | 50Hz / 60Hz Universal |
| Optional Coil Control Voltage | AC24V, 48V, 110V, 220V, 380V, 415V |
| Executive Standards | IEC 60947-4-1, GB/T 14048.4 |
| Certification | CE Mark |
| Main Terminal Mark | L1/T1, L2/T2, L3/T3 |
| Mounting Method | Screw Fixed Panel Mounting |
| Expandable Parts | Detachable NO/NC Auxiliary Contact Modules |
3. Core Product Advantages
- High-Current Silver Alloy Contact System
Silver-cadmium alloy composite contacts feature ultra-low contact resistance, strong arc ablation resistance, and extend electrical service life under long-term heavy frequent switching loads.
- Sealed Efficient Arc Extinguishing Chamber
Independent arc extinguishing structure rapidly absorbs and quenches electric arcs during circuit breaking, avoids short-circuit risks, and greatly improves operation safety for high-current working conditions.
- Anti-Vibration Stable Electromagnetic Coil
Universal 50/60Hz AC coil with low power consumption, stable pull-in and release performance. Anti-shock design adapts to vibration-intensive factory and construction site environments.
- Flame Retardant Industrial Housing
High-temperature resistant PA66 flame retardant plastic shell, anti-aging, dust-proof and moisture-proof, suitable for indoor power distribution rooms and harsh workshop production lines.
- Full Range Size Uniform Modular Design
Consistent wiring layout and installation size across all 115A~800A models, easy for unified cabinet design and spare parts replacement. Auxiliary contacts can be freely assembled for interlock and signal feedback.
- Global Export Qualified Certification
CE certified, fully meets EU electrical safety standards, supports direct export to Europe, Southeast Asia, Middle East, Africa and Latin America markets.
4. Main Application Industries & Scenarios
- Heavy-duty 3-phase asynchronous motor start-stop control
- Central air conditioning, refrigeration compressors, cooling tower fan control
- Large water pump, oil pump, industrial fan power switching
- Complete low-voltage distribution cabinets, PLC automation control systems
- CNC heavy machine tools, packaging production lines, lifting construction machinery
- Power distribution equipment for mining, chemical and textile factories
5. Standard Installation & Wiring Guide
- Vertical mounting: Fix the contactor to cabinet mounting plate via bottom screw holes to guarantee stable electromagnetic attraction.
- Main circuit wiring: 3-phase power input connects to L1, L2, L3 terminals; motor/load output connects to T1, T2, T3 terminals.
- Control circuit wiring: Connect control power to coil A1/A2 terminals strictly according to ordered coil voltage; mismatched voltage will burn the coil.
- Matching protection: Match thermal overload relay of corresponding current grade below the contactor to realize motor overload and phase loss protection.
- Auxiliary contacts: Install side-mounted auxiliary modules for interlock, indicator light and signal feedback functions.
6. Frequently Asked Questions (FAQ)
Q1: Is CJX2-F series compatible with Schneider LC1-F contactors?
Q2: Can I customize special coil voltages for bulk orders?
Q3: What’s the maximum load this series can handle?
Q4: Does this product support OEM customization?
7. Why Source Our CJX2-F Series AC Contactors?
- Professional electrical factory with over 12 years of high-current contactor R&D and production experience
- 100% full-load aging test before delivery, strict raw material inspection for stable product quality
- Complete stock of all 115A–800A models, fast lead time for bulk export orders
- Flexible OEM & ODM customization for overseas electrical distributors
- One-stop technical support for cabinet matching, wiring scheme and after-sales troubleshooting
