The LVMA PV Combiner Box Series offers a complete range of IP65 waterproof enclosures for 1 to 12 solar panel strings. Pre-configured with DC fuses, MCBs, and SPDs, these 1000V DC combiner boxes provide comprehensive overcurrent, short-circuit, and surge protection. Factory-tested and pre-wired for fast installation, they are ideal for residential rooftop, commercial, and off-grid solar systems, ensuring safe and reliable power distribution to inverters.
The LVMA PV Combiner Box Series offers a complete range of IP65 waterproof enclosures for 1 to 12 solar panel strings. Pre-configured with DC fuses, MCBs, and SPDs, these 1000V DC combiner boxes provide comprehensive overcurrent, short-circuit, and surge protection. Factory-tested and pre-wired for fast installation, they are ideal for residential rooftop, commercial, and off-grid solar systems, ensuring safe and reliable power distribution to inverters.
1. Product Overview
The LVMA PV Combiner Box Series is a versatile line of IP65-rated enclosures designed for combining and protecting solar panel strings in photovoltaic systems. Available in 1, 2, 4, 6, 8, 10, and 12-string configurations, these combiner boxes integrate essential safety components—DC fuses, main DC circuit breakers (MCBs), and surge protective devices (SPDs)—to provide complete overcurrent, short-circuit, and lightning surge protection.
Built with rugged, weatherproof enclosures and factory-prewired components, LVMA combiner boxes simplify installation, reduce on-site errors, and ensure long-term reliability in outdoor environments. The transparent hinged cover allows quick visual inspection of all components, while multiple cable glands provide secure, watertight connections. Suitable for residential rooftop arrays, commercial solar projects, and off-grid installations, the LVMA PV combiner box series is the ideal solution for safe and efficient solar power management.
2. Key Features
- Wide Range of Configurations: Available in 1, 2, 4, 6, 8, 10, and 12-string versions to suit small to medium-scale solar systems.
- All-In-One Protection: Integrated DC fuses (per string), main DC MCB, and SPD for complete circuit protection.
- 1000V DC Rated: Compatible with modern high-voltage solar panels and inverters, supporting most grid-tie and off-grid systems.
- IP65 Waterproof Enclosure: Dustproof, rainproof housing with UV resistance, suitable for outdoor installation in harsh environments.
- Transparent Inspection Cover: Allows visual check of fuse status, breaker positions, and SPD indicators without opening the enclosure.
- Factory Pre-Assembled & Tested: Components are pre-wired and tested to reduce installation time and wiring errors.
- DIN Rail Modular Design: Standard rail-mount components allow easy replacement or upgrade of fuses, breakers, or SPDs.
- Multiple Cable Glands: Pre-installed glands for secure, weatherproof input/output connections.
- Universal Compatibility: Works with all major solar panel brands and MC4-compatible connectors.
3. Technical Specifications
| Parameter | Specification |
|---|---|
| Product Series | PV Combiner Box |
| Configurations | 1/2/4/6/8/10/12 strings |
| System Voltage | 1000V DC Max |
| Rated Current | 10A/16A/20A per string (customizable) |
| Total Output Current | Up to 100A (model-dependent) |
| Enclosure Rating | IP65 (Waterproof & Dustproof) |
| Built-in Components | Per-string DC fuses, main DC MCB, SPD |
| Fuse Holder Rating | 1000V DC, 32A max |
| MCB Rating | 1000V DC, 63A/100A max (C-type) |
| SPD Rating | 1000V DC, 20–40kA surge capacity |
| Connection Type | MC4-compatible (field wiring) |
| Installation Type | Wall-mount outdoor |
| Operating Temperature | -40°C ~ +85°C |
| Compliance | IEC 61439, CE certified |
4. Working Principle
The LVMA PV combiner box serves as the central hub for solar power distribution and protection:
- String Combination: Combines power from multiple solar panel strings into a single DC output for the inverter.
- Per-String Overcurrent Protection: Individual DC fuses protect each string from overcurrent or short-circuit conditions.
- Main Circuit Isolation: The DC MCB allows safe disconnection of the entire solar array for maintenance or troubleshooting.
- Surge Protection: The SPD diverts lightning-induced or switching surges to ground, protecting the inverter and downstream equipment.
- Environmental Protection: The IP65 enclosure protects all components from rain, dust, and UV exposure, ensuring long-term reliability.
5. Applications
- Residential Rooftop Solar: Multi-string protection for home solar systems of all sizes.
- Commercial Solar: Medium-scale solar arrays, office buildings, retail installations, and industrial facilities.
- Off-Grid Systems: Remote solar installations, cabins, telecom towers, and agricultural pumping systems.
- Battery Energy Storage: Solar + battery backup systems requiring multi-string protection.
- Agricultural Solar: Large-scale farm irrigation, livestock water supply, and greenhouses.
6. Installation & Operation Instructions
- Mounting: Install the combiner box vertically on a sturdy wall or pole, ensuring cable glands face downward to prevent water ingress.
- Wiring:
- Connect the positive and negative leads from each solar panel string to the corresponding input terminals.
- Connect the combiner box output leads to the solar inverter or charge controller.
- Connect the SPD ground terminal to a proper earth grounding system.
- Operation:
- Keep the enclosure closed and the cover secured during operation to maintain the IP65 rating.
- Inspect components periodically through the transparent cover for signs of damage, discoloration, or blown fuses.
- Maintenance:
- Disconnect all solar panels before opening the enclosure for maintenance.
- Check for loose connections, damaged seals, or component wear annually.
- Replace blown fuses with matching 1000V DC PV-rated fuses only.
7. Frequently Asked Questions (FAQ)
Q1: How do I choose the right number of strings?
Select the number of strings based on your solar array design. For example, if you have 8 panels wired as 4 series strings, choose a 4-string combiner box. Always match the combiner box’s capacity to your system’s string count.
Q2: Can these combiner boxes be used outdoors?
Yes, all models have an IP65 rating, making them fully waterproof, dustproof, and UV-resistant for outdoor installation. Always mount vertically with cable glands facing down.
Q3: What is the maximum voltage supported?
All LVMA combiner boxes are rated for 1000V DC, compatible with most modern high-voltage solar panel systems.
Q4: Do I need to install all three components (fuse, MCB, SPD)?
The combiner boxes come pre-assembled with all three components for complete protection. Each serves a critical purpose:
- Fuses: Protect individual strings from overcurrent.
- MCB: Isolates the entire array for maintenance.
- SPD: Protects against lightning surges.
Q5: Can I replace components if they fail?
Yes, all components are mounted on a standard DIN rail and can be easily replaced without replacing the entire enclosure. Always use PV-rated replacement parts.
Q6: Are these combiner boxes compatible with all solar inverters?
They work with most 1000V DC solar inverters. Ensure the combiner box’s total output current matches the inverter’s DC input rating, and the system voltage does not exceed 1000V DC.
