The LMRF cylindrical ceramic fuse link is a 10×38mm cartridge safety fuse rated 500V AC, covering full current range from 1A to 32A. It adopts high-purity copper melting core and copper end caps together with fire-resistant ceramic housing, effectively suppressing surge current peaks to protect circuits. Designed for both marine vessel electrical systems and general civil industrial distribution circuits, this corrosion-resistant fuse features stable conductivity, long service life and easy installation, supplied direct from factory with full specification support.
The LMRF cylindrical ceramic fuse link is a 10×38mm cartridge safety fuse rated 500V AC, covering full current range from 1A to 32A. It adopts high-purity copper melting core and copper end caps together with fire-resistant ceramic housing, effectively suppressing surge current peaks to protect circuits. Designed for both marine vessel electrical systems and general civil industrial distribution circuits, this corrosion-resistant fuse features stable conductivity, long service life and easy installation, supplied direct from factory with full specification support.
1. Product Overview
LMRF series cylindrical ceramic fuse link is a widely used low-voltage cartridge overcurrent protection component, sized standard 10×38mm with rated voltage up to 500V. Available in complete current grades from 1A to 32A, this fuse is dual-purpose for marine ship electrical equipment and general civil industrial & household power distribution circuits.
Constructed with copper melting core, solid copper end caps and flame-retardant ceramic tube shell, it limits surge current impact and provides reliable short-circuit & overload protection for wires, control boards, motors and marine electrical appliances. Manufactured with genuine raw materials, no false current labeling, direct factory wholesale with bulk discounts and formal invoicing service.
2. Core Product Features
1. Complete Full Current Range (1A ~ 32A)
Full standard specifications to match diverse load circuit demands:
1A / 2A / 3A / 4A / 5A / 6A / 8A / 10A / 16A / 20A / 25A / 32A
Suitable for small control circuits, lighting loops, marine auxiliary equipment and medium-power machine control circuits. Custom special current specifications are available upon customer request.
2. Copper Melting Core + Solid Copper End Caps
- High-purity copper fuse core delivers stable, consistent melting characteristics, effectively weaken the damage of instantaneous current peak surges to electrical equipment
- Thick copper caps on both ends reduce contact resistance, excellent electrical conductivity, avoid overheating at terminals under long-term rated load
- Anti-oxidation plating treatment on copper parts, strong corrosion resistance to fit humid marine cabin environments
3. Fireproof Insulated Ceramic Housing
- Superior insulation and flame retardant performance, no combustion or cracking when overcurrent melts the core
- Simple compact cylindrical structure, compatible with all standard 10×38mm fuse holders
- Resists deformation under high ambient temperature inside distribution cabinets and ship electrical rooms
4. Dual Application Scenarios: Marine + Civil
- Marine use: Ship lighting, pump control, cabin auxiliary electrical panel protection
- Civil use: Household distribution boxes, machine tools, automation control boards, instrument power circuits
5. Easy Installation & Long Service Life
6. Factory Direct Supply, Reliable Quality Guarantee
3. Working Conditions
- Ambient temperature: -10℃ ~ +60℃
- Protection characteristic: Suitable for indoor cabinets and ventilated marine electrical cabins; avoid long-term immersion in water
- Atmosphere: Can withstand mild salt fog for marine use; avoid severe corrosive chemical gas environment
- Altitude: Normal performance below 2000 meters above sea level
- Humidity: Relative humidity ≤90%, no continuous condensation on fuse surface
3. Unified Technical Specifications
| Parameter | Unified Specification for LMRF Series Fuse |
|---|---|
| Model | LMRF Cylindrical Cartridge Fuse |
| Outer Dimension | 10mm diameter × 38mm length |
| Rated Voltage | 500V AC |
| Rated Current Grades | 1A,2A,3A,4A,5A,6A,8A,10A,16A,20A,25A,32A |
| Internal Melting Core Material | High purity copper |
| End Cap Material | Thickened anti-rust copper cap |
| Housing Material | Fireproof insulating ceramic tube |
| Executive Standard | IEC 269, GB/T standard low voltage fuse specification |
| Core Functions | Overload protection, short-circuit fault breaking protection |
| Applicable Scenes | Marine ship electrical systems, civil industrial & household distribution circuits |
4. Typical Applications
- Marine vessel cabin lighting, water pump, fan auxiliary electrical panels
- Household miniature distribution box branch circuit protection
- CNC machine tools, textile equipment control power circuits
- Automation instruments, sensor low-voltage power supply loops
- Small refrigeration, packaging machinery internal circuit protection
- Charging equipment, small power control cabinet safety fusing
5. Frequently Asked Questions (FAQ)
1. What’s the advantage of copper core copper cap compared to iron alloy fuses?
2. Can this LMRF fuse be used on ships?
3. What size fuse holder fits LMRF ?
4. How to select the correct current specification?
5. Does this product support customized current specifications?
6. Is the rated current marked accurate?
7. Technical documentation and support
Download the full datasheet for detailed specifications, wiring diagrams and trip coordination guides.
Please contact our technical team for custom configuration or OEM/ODM solutions for your project.
Request a quote with details about your project for volume pricing, lead times, and compliance certifications.
